Model and specification 6009 booster module

Module property non isolated boost (boost)

Rectification mode asynchronous rectification

Input range 3V ~ 32V

Output range 5V ~ 45V

Input current 4A (maximum), no-load 18ma (5V input, 8V output, no-load less than 18ma). The higher the voltage, the greater the no-load current.)

Conversion efficiency < 94% (the higher the pressure difference, the lower the efficiency)

Switching frequency 400kHz

The output ripple is 50mV (the higher the voltage is, the greater the current is, the greater the ripple is)

Load regulation rate ± 0.5%

Voltage regulation rate ± 0.5%

Working temperature - 40 ℃ ~ + 85 ℃

Overall dimension 43mm * 21mm * 14mm (L * w * h)
